Unified Interface Migration - Part 2

Introduction

Migration of Dynamics 365 legacy web client interfaces to Unified interface is not an easy process, especially for complex and highly customized implementation. Once Unified Interface has been enabled from the admin center, it would require an extensive verification and validation end to end before handover to the business users.


This article is intended to explain how you can enable the Unified interface of Dynamics 365 implementation in multiple phases to overcome the load of verifying the entire application simultaneously and give the flexibility to onboard the user to the application in stages.


Benefits:

  • This approach will give the flexibility to enable Unified Interface in multiple phases.

  • Privilege to migrate a selected set of functionality/interfaces over the unified interface.

  • A cost-effective approach can be starting migration with fewer resources.

  • Less effort in planning as this migration will be commenced in multiple phases.

  • This also gives privilege to the customer to see the look & feel of the new interface without waiting for complete migration.

  • Safety benefits to avoid any uncertainty that may not be supported over new interface will not be the showstopper for the entire application use.

  • The modular approach recommended for higher quality output.

Let’s dive deep in the customize unified interface migration approach


In this demo, I have divided the migration into three phases, but You can divide into multiple phases based on the independent set of working areas.

Modules to be migrate

  • Public Affairs

  • Sales

  • Customer Service

It's recommended that customization/change over in dynamics must be managed by solution. The solution is a container for all the customized components of a specific implementation. Solutions are also used to migrating changes from one environment to another.


Step 2- Create a new solution named “Unified Interface Migration” to store the migration component.


Note: An initial solution version can be named version 1.0.0.0 (major.minor.build.revision), but you can also use a date format 2018.04.10.01 (yyyy.mm.dd.revision).


Major is incremented every time you introduce some significant functionality or upgraded to a new version of CRM.


Minor is incremented every time you release an update to the solution that introduces minor features that are building on existing functionality.


Build & revision is incremented with every single release - e.g. bug fixes

Step 3- Create a Model Driver App named “Unified Interface Migration” from the dynamics 365 home interface.

Step 4- Use the newly created solution as the source for this app.

Step 5- Add a site map in the solution.

Step 6- add the app also in the solution area.

All the above steps are pre-requisite to creating a package, to contain the component for unified interface enablement, testing, and this will use to migrate the change to other instances.


Let’s start the first phase of migration


In the first phase, some common entities are included that used across the application like account, contact task, etc. All these entities are required to add in the sitemap as menu options.

The added options in the sitemap.

  • Area - Public Affairs

  • Group - Customer

  • Sub Area - Account, Contact & Task

Sitemap menu options configuration


Account

  • Type - Entity

  • Entity - Account

  • ID: - You can change, the default value opted here that provided by the app.

  • Icon: - Default option provided by the app

Contact

  • Type - Entity

  • Entity - Contact

  • ID - Default value provided by the app

  • Icon - Default option provided by the app

Task

  • Type - Entity

  • Entity - Task

  • ID - Default value provided by the app.

  • Icon - Default option provided by the app

Now, all done for the first phase of migration, let's save, validate & publish the app.


Final Version of the First release

In the first release, we have enabled the Unified interface for engagement area that includes common entities account, contact, and task.


The second phase of migration

Here the target is to enable the unified interface for the “Sales” module, so added two sales-related entities i.e. Lead & opportunity.


Sitemap menu options configuration

  • Area - Sales

  • Group - General

  • Sub Area - Lead & Opportunity

The menu options are configured similarly as the first release. Please refer to this sitemap menu configuration of the first phase.


Final Outcome of the second release :

The unified interface enabled for lead & opportunity interfaces.



The third phase of migration

The third phase targeted to enable the unified interface for the “Customer Service” module, so added two entities i.e. Case & Queue.


Sitemap menu options configuration

  • Area - Customer Service

  • Group - Service

  • Sub Area - Case & Queue


The menu options are configured similarly as the first release. Please refer to this sitemap menu configuration of the first phase.


Final Outcome of the third release :

The unified interface enabled for case & queue interfaces.


This is the overall process to enable the Unified interface for dynamics implementation is multiple stages.


Part 1- Unified Interface Migration - Part 1


Happy learning.
